LL-OTP3.0-A
P3 outdoor full-color LED display screen (320 x 160)
Boasting a refresh rate of over 3840 Hz and 14-bit+ grayscale, it delivers delicate, lifelike images with stable and uniform brightness, zero flicker and grain-free visuals;Equipped with upper-column and lower-column blanking functions, it supports high refresh rates while resolving issues including dark first lines, color cast at low grayscale, and pixel speckles;Adopting SMD1515 LEDs integrated with red, green and blue chips for superior color uniformity, it achieves a contrast ratio of 5000:1 and a viewing angle exceeding 140°. It features outstanding reliability and an extended service life.
Product Features
High Refresh Rate & High Grayscale
Boasting a refresh rate of over 3840 Hz and 14-bit+ grayscale, it delivers delicate, lifelike images with stable and uniform brightness, zero flicker and grain-free visuals.
Driver Solution
Equipped with upper-column and lower-column blanking functions, it supports high refresh rates while resolving issues including dark first lines, color cast at low grayscale, and pixel speckles.
Wide Viewing Angle & High Contrast Ratio
Adopting SMD1515 LEDs integrated with red, green and blue chips for superior color uniformity, it achieves a contrast ratio of 5000:1 and a viewing angle exceeding 140°. It features outstanding reliability and an extended service life.
Parameters
| Parameter Category | Parameter | Parameter value |
|---|---|---|
| Module Parameters | Parameter / Model | LL-OTP3.0-A |
| Pixel Structure | SMD1515 LED | |
| Pixel Pitch (mm) | 3.076 | |
| Module Resolution (W×H) | 104×52=5408 | |
| Module Dimension (mm) | 320×160 | |
| Module Weight (kg) | 0.41 | |
| Module Input Voltage (V) | 5±0.1 | |
| Module Max Current (A) | ≤9 | |
| Module Max Power Consumption (W) | ≤45 | |
| Cabinet Parameters | Module Configuration per Cabinet (W×H) | 3×6 |
| Cabinet Resolution (W×H) | 312×312 | |
| Cabinet Dimension (mm) | 960×960×80 | |
| Cabinet Area (m²) | 0.9216 | |
| Cabinet Weight (kg) | 36-38 | |
| Cabinet Pixel Density (dots/m²) | 111111 | |
| Cabinet Flatness (mm) | ≤0.3 | |
| Maintenance Method | post-maintenance | |
| Cabinet Material | Iron | |
| Cabinet Parameters | Module Configuration per Cabinet (W×H) | 3×6 |
| Cabinet Resolution (W×H) | 312×312 | |
| Cabinet Dimension (mm) | 960×960×80 | |
| Cabinet Area (m²) | 0.9216 |
